ES-3-T2MK

제품 사양

Contact Rating

R- 0.4 VA max @ 20 V AC or DC

Electrical Life

30,000 make and break cycles at full load

Contact Resistance

20 mΩ max. initial @2-4 VDC,100 mA

Insulation Resistance

1,000 MΩ min.

Dielectric Strength

1,500 V RMS @ sea level.

ESD Resistant Option

P2 insulating actuator

only

9,000 VDC min. @ sea level,actuator to terminals.

Degree of Protection

IP67

Operating Temperature

-30°C to 85°C

Configuration

SPDT

품번

ES-3-T2MK

주요 용도

取暖器 heater; 电风扇 Electric fan; 监控摄像头 Surveillance camera; 冰箱 refrigerator; 空调air conditioning; 转向射灯 to shoot the light; 洗衣机 washing machine; 饮水机等家用电器 water dispenser; 其他机械设备Other mechanical equipment
