FIG. S-03DF-9290
제품 사진 · IEC 전원 인렛 / Switch + dual fuse + filter + socket (4 in 1)
Switch + dual fuse + filter + socket (4 in 1)양산 중
S-03DF-9290
Dual stage filterUltra compact design
제품 사양
- Rated Voltage
- 115/250VAC
- Operating Frequency
- 50/60Hz
- Withstanding Voltage
- 1500VDC (line/line)
- Insulation Resistance
- >50MΩ@500VDC
- Temperature Rise
- <30℃
- Climatic Category
- 25/085/21
- Housing Material
- Nickel-plated iron
- Rated Current
- 1A, 3A, 6A, 10A
- 품번
- S-03DF-9290
주요 용도
Dual stage filter，Ultra compact design; Rated currents up to 10 A; Dual fuse holder，2-pole rocker switch; Good attenuation performance; Faston or spring cage terminals; Consumer goods; EDP and office equipment; Single-phase and switch-mode power supplies; Test and measurement equipment; Medical electrical devices (MD) and InVitro-Diagnostics (IVD) equipment; Audio/Video, information and communicatio
최소 주문 수량(MOQ)이 적용됩니다. 맞춤 도금 및 포장은 요청 시 제공됩니다.
도면
DRAWING
