FIG. ES-9-T2R-S
제품 사진 · 토글 스위치 / ES40-T
ES40-T양산 중
ES-9-T2R-S
Electric fan
제품 사양
- Contact Rating
- R- 0.4 VA max @ 20 V AC or DC
- Electrical Life
- 30,000 make and break cycles at full load
- Contact Resistance
- 20 mΩ max. initial @2-4 VDC,100 mA
- Insulation Resistance
- 1,000 MΩ min.
- Dielectric Strength
- 1,500 V RMS @ sea level.
- ESD Resistant Option
- P2 insulating actuator
- only
- 9,000 VDC min. @ sea level,actuator to terminals.
- Degree of Protection
- IP67
- Operating Temperature
- -30°C to 85°C
- 품번
- ES-9-T2R-S
주요 용도
取暖器 heater; 电风扇 Electric fan; 监控摄像头 Surveillance camera; 冰箱 refrigerator; 空调air conditioning; 转向射灯 to shoot the light; 洗衣机 washing machine; 饮水机等家用电器 water dispenser; 其他机械设备Other mechanical equipment
최소 주문 수량(MOQ)이 적용됩니다. 맞춤 도금 및 포장은 요청 시 제공됩니다.
도면
DRAWING
