NR01103

제품 사양

Logic Level

0.4VA maximum @ 28V AC/DC maximum

Contact Resistance

100 milliohms maximum

Insulation Resistance

100 megohms minimum @ 500V DC

Dielectric Strength

500V AC minimum for 1 minute minimum

Mechanical Life

30,000 cycles minimum

Electrical Life

10,000 cycles minimum

Nominal Operating Torque

0.02Nm (0.177 Ib.in)

Contact Timing

Nonshorting

Indexing

45° for 3-position, 4-position & 5-position

품번

NR01103

주요 용도

FEAtuRES; • Requires Minimum Distance Behind; the Panel; • Adjustable Stop Types Provide; Prototypes Immediately; • Industrial Quality, Economically; Priced; • RoHS Compliant
