TS1-00-00O-0N-32S

The light touch switch has the advantages of small contact resistance load, accurate operating force error and diversified specifications, and has been widely used in electronic…

제품 사양

Circuit: SPST 1P1T
Current Rating: 50mA
Voltage Rating: 12VDC
Dielectric withstanding voltage: 250VAC for 1 minute
Contact Resistance: 100mΩ Max .(intial)
Insulation Resistance: 100MΩ Min,
Operating Force: 180±50gf or 250±50gf
Total Travel: 0.25±0.1mm
Life Cycles: 200,000 Cycles Min
Solder Specifications: 260°C for 3 Seconds
Function: Momentary
Operating Temperature: -20°C~ +70°C
품번: TS1-00-00O-0N-32S

주요 용도

The light touch switch has the advantages of small contact resistance load, accurate operating force error and diversified specifications, and has been widely used in electronic equipment and white household appliances.

최소 주문 수량(MOQ)이 적용됩니다. 맞춤 도금 및 포장은 요청 시 제공됩니다.
