PA12-12-HL-BO-O2-3

• Electronic handle

제품 사양

Resistive: 115VAC,60Hz 3A 1A(DB)25,000cycles
Inductive: 28VDC 2A 2A(DB)25,000cycles
Contact Resistance: 50mΩ Max.
lnsulation Resistance: 1GΩ @ 500DVc
Dielectric Strength: AC 1000V 1 minute
Mechanical Life: 1,000,000cycles
Operating Temperation: -40°C~+85°c
Switch action: Momentray
Switch circuitry: SPDT-DB，load 1N.O./1N.C. 2 Circuit Life
Actuator Ingress Protection: IP68
Total traver: 1.6mm max.
Operating Force: 1.7lbs [770g]. Release Force :12oz [340g]
Stands: UL61058 ROHS
품번: PA12-12-HL-BO-O2-3

주요 용도

• Electronic handle 电控手柄 • Off-road transportation 户外交通运输 • Joysticks 操纵杆 • Typically used in cranes 起重机 • Construction equipment 建筑工程机械 • Agricultural equipment 农业设备 • Mining,equipment. 采矿设备 • Computers & network equipment 电脑周边设备

최소 주문 수량(MOQ)이 적용됩니다. 맞춤 도금 및 포장은 요청 시 제공됩니다.
