FIG. TS-13-A1-2-BQ
제품 사진 · DIP · 슬라이드 스위치 / T80-S
T80-S양산 중
TS-13-A1-2-BQ
Household Products
제품 사양
- CONTACT RATING
- 5A @120 VAC or 28 VDC
- ELECTRICAL LIFE
- 30,000 make-and-break cycles at full load
- CONTACT RESISTANCE
- 10 mΩ max. initial @2-4 VDC, 100 mA
- INSUL ATION RESISTANCE
- 1,000 MΩ min.
- DIELECTRIC STRENGTH
- 1 ,500 V RMS @ sea level.
- OPERATING TEMPERATURE
- -30°C to 85°C
- 품번
- TS-13-A1-2-BQ
주요 용도
Household Products; Hood Panel; Wall switch; Video Doorbell, hotel access; Bathroom Equipment; Elevator operator Panel; Medical equipment,; Pharmaceutical equipment; Food processing equipment; Automotive Electronics
최소 주문 수량(MOQ)이 적용됩니다. 맞춤 도금 및 포장은 요청 시 제공됩니다.
도면
DRAWING
주문 코드 체계
ORDER CODING
